Belimo H6015X1-S2 - 2-way globe valve DN 15

Name: Belimo H6015X1-S2 - 2-way globe valve DN 15
Brand: Belimo
SKU: H6015X1-S2
Price: 2265.41 PLN
Availability: BackOrder

Belimo

zł2,265.41

VAT included

zł1,841.80 tax excluded

Belimo H6015X1-S2 2-way globe valve with flanged connection, DN 15, PN 25 and Kvs 1 m³/h. Designed for closed water and steam systems in non-critical applications.

Medium temperature: 5...150°C [41...302°F]. The flow characteristic is equal-percentage, and permissible leakage is max. 0.05% of the Kvs value.

Delivery in approx. 14 days

Belimo H6015X1-S2 – 2-way globe valve

Flanged valve for modulating control on the water side of ventilation and heating systems. The technical data sheet specifies use in closed water and steam systems in non-critical applications.

Key technical data

Design: 2-way; DN 15; PN 25; stroke 15 mm.
Kvs: 1 m³/h; equal-percentage flow characteristic.
Medium: water and steam (Δp/P1 <0,4), water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 2500 kPa, 150°C up to 2430 kPa.
Permissible leakage: max. 0.05% of the Kvs value.
Pipe connection: flange according to ISO 7005-2.
Body: EN-GJS-400-18-LT (GGG 40.3); plug, stem and seat: stainless steel; stem seal: PTFE V-ring.

Installation notes

Permissible installation position: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted. Observe the direction of flow indicated by the arrow on the body. The maximum differential pressure and closing pressure depend on the actuator fitted.
