Belimo H6040X16-S2 - 2-way globe valve

Name: Belimo H6040X16-S2 - 2-way globe valve
Brand: Belimo
SKU: H6040X16-S2
Price: 3019.70 PLN
Availability: BackOrder

Belimo

zł3,019.70

VAT included

zł2,455.04 tax excluded

Belimo H6040X16-S2 is a 2-way globe valve DN 40 with PN 25 flanged connection. Kvs is 16 m³/h, and the medium temperature is 5...150°C [41...302°F].

Designed for continuous control on the water side of ventilation and heating systems, as well as for closed water and steam systems in non-critical applications.

Delivery in approx. 14 days

Belimo H6040X16-S2 – 2-way globe valve

A valve with flanged connection for closed water and steam systems in non-critical applications. Designed for continuous control on the water side of ventilation and heating systems.

Key technical data

Type: 2-way globe valve, DN 40, PN 25; flanged connection in accordance with ISO 7005-2.
Kvs: 16 m³/h; stroke: 15 mm.
Medium: water and steam (Δp/P1 <0,4), and water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 2500 kPa, 150°C up to 2430 kPa.
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Body: EN-GJS-400-18-LT (GGG 40.3) with protective coating; closing element, stem and seat made of stainless steel; stem seal: PTFE V-ring.
Mounting position: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.

The valve is operated by an actuator for globe valves. Maximum differential pressure and closing pressure depend on the actuator installed.
