Belimo H614R - 2-way globe valve

Name: Belimo H614R - 2-way globe valve
Brand: Belimo
SKU: H614R
Price: 1056.39 PLN
Availability: BackOrder

Belimo

zł1,056.39

VAT included

zł858.85 tax excluded

Belimo H614R is a DN 15 2-way globe valve with a PN 6 flange connection and Kvs 2.5 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H614R is a 2-way globe valve with a flange connection, designed for control in closed water systems. The valve operates with a globe valve actuator.

Key features

DN 15, PN 6, Kvs 2.5 m³/h; stroke 15 mm.
Medium: water or water with a maximum of 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
Flow characteristic: equal-percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0.05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element and stem made of stainless steel; stem seal: EPDM O-ring.
Installation with the stem positioned from vertical to horizontal; installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H614R
EAN13

7630498106118

Kvs

2.5 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
