Belimo H650R - 2-way globe valve

Name: Belimo H650R - 2-way globe valve
Brand: Belimo
SKU: H650R
Price: 1860.71 PLN
Availability: BackOrder

Belimo

zł1,860.71

VAT included

zł1,512.77 tax excluded

Belimo H650R is a 2-way DN 50 globe valve with a PN 6 flange connection. The Kvs value is 40 m³/h, and the medium temperature range is -10...120°C [14...248°F].

Designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H650R – DN 50 globe valve

2-way globe valve with a flange connection, designed for closed water systems and water-side control in ventilation and heating systems.

Key features

DN 50, PN 6; pipe connection: flange.
Kvs: 40 m³/h; stroke: 15 mm.
Medium: water or water with a maximum of 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: equal percentage; leakage rate: max. 0.05% of the Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.

For a medium temperature of -10...2°C, the technical data sheet indicates that stem heating is required. Installation is permitted from vertical to horizontal with respect to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.

Brand

Belimo
Reference

H650R
EAN13

7630498106330

Kvs

40 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
