Belimo H732N - 3-way globe valve DN 32

Name: Belimo H732N - 3-way globe valve DN 32
Brand: Belimo
SKU: H732N
Price: 1471.23 PLN
Availability: BackOrder

Belimo

zł1,471.23

VAT included

zł1,196.12 tax excluded

Belimo H732N is a 3-way globe valve with flanged connection, DN 32, PN 16 and Kvs 16 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H732N – 3-way globe valve

Flanged valve for closed water systems, designed for water-side control in ventilation and heating systems.

Key features

Nominal size DN 32, nominal pressure PN 16, Kvs 16 m³/h.
Pipe connection: flange; body: EN-GJL-250 (GG 25).
Medium: water or water with a maximum of 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F]. At a medium temperature of -10...2°C, the technical datasheet indicates that stem heating is required.
Flow characteristic: A – AB equal percentage, B – AB linear.
Permissible leakage: A – AB max. 0.05% of Kvs value; B – AB max. 1% of Kvs value.
Stroke: 15 mm.
Permissible mounting position: from vertical to horizontal relative to the axis; installation with the axis pointing downwards is not permitted.

Brand

Belimo
Reference

H732N
EAN13

7630498106804

Kvs

16 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
