Belimo R438 - 2-way ball valve with control orifice

Belimo R438 - 2-way ball valve with control orifice

Belimo
zł791.65
VAT included
zł643.62 tax excluded

Belimo R438 is a 2-way ball valve with a control orifice, DN 40, PN 25, with a G 2 1/4" male thread and Kvs 16 m³/h. Designed for water and water with a maximum of 50% by volume glycol.

The medium temperature is -10...100°C [14...212°F]. The valve has an equal-percentage characteristic and leakage class A.

Delivery in approx. 14 days
Share

Belimo R438 – 2-way control valve

Ball valve with a control orifice for controlling flow on the water side of ventilation and heating systems. Designed for open and closed water systems. The integrated orifice provides an equal-percentage characteristic.

Key technical data

  • Type: 2-way; DN 40; PN 25.
  • Connection: G 2 1/4" male thread, in accordance with ISO 228-1.
  • Kvs: 16 m³/h; ps 1600 kPa.
  • Medium: water, water with a maximum of 50% by volume glycol.
  • Medium temperature: -10...100°C [14...212°F].
  • Differential pressure: ∆pmax 200 kPa; closing pressure: 1400 kPa.
  • Flow characteristic: equal-percentage; permissible leakage: bubble-tight, leakage class A.
  • Body: nickel-plated brass; closing element and stem: stainless steel.
  • Rotation angle: 90°; operating range: 15...90°.

At a medium temperature of -10...2°C, extending the valve neck is recommended. The permissible medium temperature may depend on the actuator type; limitations are specified in the relevant actuator data sheets. Installation is permitted from vertical to horizontal relative to the stem, but not with the stem pointing downwards.

  • Brand
    Belimo
  • Reference
    R438
  • EAN13
    7630498108204

  • Kvs
    16 m³/h
  • Medium
    Water, water with up to 50% vol. glycol.
  • Pattern
    2-way
  • Fluid temperature
    -10...100°C [14...212°F]
  • Fluid temperature, note
    At a fluid temperature of -10...2°C, extending the valve neck is recommended. The permissible fluid temperature may be limited depending on the actuator type. Refer to the relevant actuator data sheets for limitations.
  • Differential pressure
    ∆pmax 200 kPa
  • Closing pressure
    1400 kPa
  • Flow characteristic
    Equal-percentage characteristic
  • Permissible leakage
    Bubble-tight, leakage class A
  • Pipe connection
    External thread

Techniczna karta katalogowa

Download (776.39KB)

Instrukcja montażu

Download (556.22KB)

Techniczna karta katalogowa – R4.. modulating

Download (778.77KB)

EU Declaration of Conformity – R5.. / R4.. DN 15...50

Download (55.18KB)

Environmental Declaration – R4..

Download (70.44KB)
In business since 2005
Over 20 years of experience
A trusted partner
Reliable service and customer trust
Technical support
Help with selecting and operating equipment
