Belimo CM230G-F-R - damper actuator

Name: Belimo CM230G-F-R - damper actuator
Brand: Belimo
SKU: CM230G-F-R
Price: 840.09 PLN
Availability: OutOfStock

Belimo

zł840.09

VAT included

zł683.00 tax excluded

Belimo CM230G-F-R damper actuator with 2 Nm torque, powered by AC 100...240 V. Supports Close/Open, 3-point control; motor running time is 75 s / 90°.

Mechanical connection: form-fit connection 8x8 mm. IEC/EN IP66 protection requires installation with the rear side firmly against the damper housing.

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo CM230G-F-R damper actuator

Actuator designed to control air dampers in building services systems. The manufacturer specifies a damper size of up to approx. 0.4 m².

Key features

Motor torque: 2 Nm; control: Close/Open, 3-point.
Rated voltage: AC 100...240 V; frequency: 50/60 Hz.
Motor running time: 75 s / 90°; motor direction of rotation: clockwise (cw).
Angle of rotation: 0...287.5°; adjustment by means of mechanical end stops.
Mechanical connection: form-fit connection 8x8 mm. Manual adjustment using a magnet.
Power and control connection: 1 m cable, 3x 0.75 mm².
Power consumption during operation: 1.5 W; at rest: 1 W; for cable sizing: 3 VA.
IEC/EN protection rating: IP66; IEC/EN protection class: II, reinforced insulation.
Ambient temperature: -30...50°C [-22...122°F].

The actuator is mounted directly on the damper shaft and secured with the Z-ARCM anti-rotation clip included in the set. The position indicator contains a magnet used to disengage the gearbox during manual adjustment.

Installation note: IP66 protection requires the rear side of the actuator to fit firmly against the damper housing. When installed rotated by 180°, the manufacturer guarantees only IP54.
