Belimo H514B - 3-way globe valve DN 15

Belimo H514B – technical data

3-way globe valve for open and closed water systems. It is designed for continuous water-side control in ventilation and heating systems.

• DN 15; PN 16; ps 1600 kPa.
• Connection: G 1 1/8" male thread, in accordance with ISO 228-1.
• Kvs: 2.5 m³/h; stroke: 15 mm.
• Medium: water or water with a maximum of 50% by volume glycol.
• Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
• Flow characteristic: A – AB equal percentage, B – AB linear.
• Permissible leakage: A – AB max. 0.05% of Kvs value; B – AB max. 1% of Kvs value.
• Valve body: CC499K; plug and stem: stainless steel; stem seal: EPDM O-ring.

The valve can be installed with the stem from vertical to horizontal; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
