Belimo H6015X1P6-S2 - 2-way globe valve DN 15

Name: Belimo H6015X1P6-S2 - 2-way globe valve DN 15
Brand: Belimo
SKU: H6015X1P6-S2
Price: 2265.41 PLN
Availability: BackOrder

Belimo

zł2,265.41

VAT included

zł1,841.80 tax excluded

Belimo H6015X1P6-S2 is a 2-way globe valve with a flanged connection, DN 15, PN 25 and Kvs 1.6 m³/h. It is designed for water-side control in closed water and steam systems.

Medium temperature: 5...150°C [41...302°F]. Flow characteristic: equal percentage.

Delivery in approx. 14 days

Belimo H6015X1P6-S2 – 2-way globe valve

A valve with a flanged connection, designed for non-critical closed water and steam systems and for water-side control in ventilation and heating systems.

Key features and technical data

DN 15, PN 25; Kvs 1.6 m³/h.
Stroke: 15 mm.
Medium: water and steam (Δp/P1 <0,4), and water with up to 50% by volume glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 2500 kPa, 150°C up to 2430 kPa.
Flow characteristic: equal percentage, optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Pipe connection: flange according to ISO 7005-2.
Body: EN-GJS-400-18-LT (GGG 40.3), with protective coating; plug, stem and seat: stainless steel; stem seal: PTFE V-ring.
Installation position: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.

The valve is operated by a globe valve actuator. The maximum differential pressure and closing pressure depend on the actuator installed. During installation, observe the flow direction indicated by the arrow on the body.
