Belimo H612R - 2-way globe valve

Name: Belimo H612R - 2-way globe valve
Brand: Belimo
SKU: H612R
Price: 1056.39 PLN
Availability: BackOrder

Belimo

zł1,056.39

VAT included

zł858.85 tax excluded

Belimo H612R is a DN 15 2-way globe valve with a PN 6 flanged connection and Kvs 1 m³/h. Designed for water-side control in ventilation and heating systems with a closed water circuit.

Medium temperature: -10...120°C [14...248°F]. Permitted medium: water or water with up to 50% by volume glycol.

Delivery in approx. 14 days

Belimo H612R – 2-way globe valve

Valve for water-side control in ventilation and heating systems with a closed water circuit. The flanged connection complies with ISO 7005-2.

Key features

DN 15, PN 6, Kvs 1 m³/h.
Stroke: 15 mm.
Medium: water, water with up to 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: equal-percentage, optimised in the opening range.
Permissible leakage: max. 0.05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Permissible mounting position: from vertical to horizontal relative to the stem; mounting with the stem pointing downwards is not permitted.

Stem heating is required at a medium temperature of -10...2°C. Observe the flow direction indicated by the arrow on the body. The maximum differential pressure and closing pressure depend on the actuator fitted.

Brand

Belimo
Reference

H612R
EAN13

7630498106057

Kvs

1 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
