Belimo H750R - 3-way globe valve DN 50

Name: Belimo H750R - 3-way globe valve DN 50
Brand: Belimo
SKU: H750R
Price: 1438.92 PLN
Availability: BackOrder

Belimo

zł1,438.92

VAT included

zł1,169.85 tax excluded

Belimo H750R is a 3-way globe valve with PN 6 flanged connection. DN 50, Kvs 40 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H750R – 3-way globe valve

Valve with PN 6 flanged connection, designed for closed water systems and water-side control in ventilation and heating systems.

Key technical data

DN 50; Kvs 40 m³/h; stroke 15 mm.
Medium: water or water with max. 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F]. At temperatures of -10...2°C, the technical data sheet specifies that stem heating is required.
Flow characteristic: A – AB equal-percentage; B – AB linear.
Permissible leakage: A – AB max. 0.05% of Kvs value; B – AB max. 1% of Kvs value.
Valve body: EN-GJL-250 (GG 25); plug and stem in stainless steel; stem seal: EPDM O-ring.
Pipe connection: flange according to ISO 7005-2.

Permitted installation from vertical to horizontal relative to the valve axis; installation with the stem pointing downwards is not permitted. The flow direction must match the arrow on the body. Maximum differential pressure and closing pressure depend on the actuator fitted.

Brand

Belimo
Reference

H750R
EAN13

7630498106873

Kvs

40 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
