Belimo H613S - 2-way globe valve DN 15 images
Belimo H613S - 2-way globe valve DN 15
Price:
zł1,355.95
VAT included
zł1,102.40 tax excluded
Belimo H613S is a 2-way globe valve with flanged connection, DN 15, PN 16 and Kvs 1.6 m³/h. Fluid temperature: 5...150°C [41...302°F].
Belimo H613S is a 2-way globe valve for closed water and steam systems in non-critical applications. It is designed for modulating control on the water side of ventilation and heating systems.
Key features
- DN 15, PN 16; flanged connection in accordance with ISO 7005-2.
- Kvs 1.6 m³/h; stroke 15 mm.
- Fluid: water and steam (Δp/P1 <0,4), water with a maximum of 50% by volume glycol.
- Fluid temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
- Equal-percentage characteristic; permissible leakage: max. 0,05% of the Kvs value.
- Body: EN-GJL-250 (GG 25); closing element, stem and seat made of stainless steel.
- Installation permitted from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.
-
Brand
-
ReferenceH613S
-
EAN137630498106095
-
Kvs1.6 m³/h
-
MediumWater and steam (Δp/P1 ＜0,4), water with max. 50% vol. glycol.
-
Pattern2-way
-
Fluid temperature5...150°C [41...302°F]
-
Fluid temperature, note120°C up to 1600 kPa 150°C up to 1400 kPa
-
Flow characteristicEqual-percentage characteristic
-
Permissible leakageMax. 0.05% of Kvs value
-
Pipe connectionFlange
