Belimo H614S - 2-way globe valve

Name: Belimo H614S - 2-way globe valve
Brand: Belimo
SKU: H614S
Price: 1355.95 PLN
Availability: BackOrder

zł1,355.95

VAT included

zł1,102.40 tax excluded

Belimo H614S 2-way globe valve, DN 15, PN 16, with flanged connection. Kvs 2.5 m³/h; medium temperature 5...150°C [41...302°F].

Designed for closed water and steam systems and for water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H614S – 2-way globe valve

Flanged valve for closed water and steam systems in non-critical applications. Used for water-side control in ventilation and heating systems.

DN 15, PN 16, Kvs 2.5 m³/h; stroke 15 mm.
Medium: water and steam (Δp/P1 <0,4), and water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Flow characteristic: equal percentage; permissible leakage: max. 0,05% of the Kvs value.
Flanged connection in accordance with ISO 7005-2; body made of EN-GJL-250 (GG 25).
Closing element, stem and seat made of stainless steel; stem seal: PTFE V-ring.
Permitted installation position: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted.
