Belimo H619S - 2-way globe valve DN 20

Name: Belimo H619S - 2-way globe valve DN 20
Brand: Belimo
SKU: H619S
Price: 1448.41 PLN
Availability: BackOrder

Belimo

zł1,448.41

VAT included

zł1,177.57 tax excluded

Belimo H619S is a 2-way globe valve with flanged connection, PN 16, DN 20 and Kvs 4 m³/h. Designed for water-side control in ventilation and heating systems.

Medium temperature is 5...150°C [41...302°F]. The valve has an equal-percentage characteristic and a permissible leakage rate of max. 0.05% of the Kvs value.

Delivery in approx. 14 days

Belimo H619S – 2-way globe valve

Valve with flanged connection for closed water and steam systems in non-critical applications. Designed for continuous water-side control in ventilation and heating systems.

Key features

DN 20, PN 16, Kvs 4 m³/h; stroke 15 mm.
Medium: water and steam (Δp/P1 <0,4), water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Equal-percentage characteristic; permissible leakage: max. 0.05% of the Kvs value.
Flanged connection in accordance with ISO 7005-2.
Body: EN-GJL-250 (GG 25); closure element, stem and seat: stainless steel; stem seal: PTFE V-ring.

Permitted installation position ranges from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
