Belimo H650N - 2-way globe valve DN 50

Name: Belimo H650N - 2-way globe valve DN 50
Brand: Belimo
SKU: H650N
Price: 2295.17 PLN
Availability: BackOrder

Belimo

zł2,295.17

VAT included

zł1,865.99 tax excluded

Belimo H650N is a 2-way globe valve with flanged connection, DN 50, PN 16 and Kvs 40 m³/h. Designed for closed water circuits and water-side control in ventilation and heating systems.

Suitable for water and water with a maximum of 50% vol. glycol at a medium temperature of -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H650N – 2-way globe valve

Flanged valve for closed water circuits, designed for water-side control in ventilation and heating systems. The body is made of EN-GJL-250 (GG 25).

Key features

Nominal size: DN 50; nominal pressure: PN 16; connection: flange.
Kvs: 40 m³/h; stroke: 15 mm.
Medium: water, water with a maximum of 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Closing element and stem: stainless steel; stem seal: EPDM O-ring.

Installation is permitted from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.

Brand

Belimo
Reference

H650N
EAN13

7630498106323

Kvs

40 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
