Belimo H650S - 2-way globe valve DN 50

Name: Belimo H650S - 2-way globe valve DN 50
Brand: Belimo
SKU: H650S
Price: 2767.64 PLN
Availability: BackOrder

Belimo

zł2,767.64

VAT included

zł2,250.11 tax excluded

Belimo H650S is a 2-way globe valve with a flanged connection, DN 50, PN 16 and Kvs 40 m³/h. It is designed for water-side control in ventilation and heating systems.

Fluid temperature is 5...150°C [41...302°F]. Permitted fluids are water and steam (Δp/P1 <0,4), as well as water with max. 50% vol. glycol.

Delivery in approx. 14 days

Belimo H650S – 2-way globe valve

Flanged valve for closed-loop systems with water and steam in non-critical applications. It is used for continuous control on the water side of ventilation and heating systems.

Key features

Design: 2-way; DN 50; PN 16; Kvs 40 m³/h.
Pipe connection: flange, in accordance with ISO 7005-2.
Fluid: water and steam (Δp/P1 <0,4), water with max. 50% vol. glycol.
Fluid temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0,05% of the Kvs value.
Stroke: 15 mm.
Body: EN-GJL-250 (GG 25); closing element, stem and seat: stainless steel; stem seal: PTFE V-ring.

Installation notes

Installation is permitted with the stem between vertical and horizontal; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. Maximum differential pressure and close-off pressure depend on the actuator installed.
