Belimo H650SP - 2-way globe valve DN 50

Name: Belimo H650SP - 2-way globe valve DN 50
Brand: Belimo
SKU: H650SP
Price: 8159.73 PLN
Availability: BackOrder

Belimo

zł8,159.73

VAT included

zł6,633.93 tax excluded

Belimo H650SP is a 2-way globe valve with a partially pressure-balanced plug, flanged connection, PN 16 and Kvs 40 m³/h. Intended for closed water and steam systems in non-critical applications.

Medium temperature is 5...150°C [41...302°F]. The valve has an equal-percentage characteristic and a permissible leakage rate of max. 0.05% of the Kvs value.

Delivery in approx. 14 days

Belimo H650SP – globe valve

2-way globe valve with a partially pressure-balanced plug for continuous control on the water side of ventilation and heating systems. According to the documentation, it is intended for closed water and steam systems in non-critical applications.

Key features

DN 50, PN 16, ps 1600 kPa; flanged connection according to ISO 7005-2.
Kvs 40 m³/h; stroke 15 mm.
Medium: water and steam (Δp/P1 <0,4), water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C at 1600 kPa, 150°C at 1400 kPa.
Equal-percentage characteristic; permissible leakage rate of max. 0.05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element, stem and seat made of stainless steel; stem seal: PTFE V-ring.

Installation instructions

Permissible mounting position: from vertical to horizontal in relation to the stem. Installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. The maximum differential pressure and closing pressure depend on the actuator installed.
