Belimo H679R - 2-way globe valve DN 80

Name: Belimo H679R - 2-way globe valve DN 80
Brand: Belimo
SKU: H679R
Price: 2977.24 PLN
Availability: BackOrder

Belimo

zł2,977.24

VAT included

zł2,420.52 tax excluded

Belimo H679R is a 2-way globe valve with a PN 6 flange connection, DN 80 and Kvs 90 m³/h. It is designed for water-side control in closed ventilation and heating systems.

Delivery in approx. 14 days

Belimo H679R globe valve

2-way flanged valve for water-side control in ventilation and heating systems with closed water circuits. The valve is actuated by a globe valve actuator.

Key features

Nominal diameter DN 80; PN 6 flange connection.
Kvs: 90 m³/h; stroke: 18 mm.
Medium: water or water with a maximum of 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F]. At a medium temperature of -10...2°C, the technical data sheet specifies that stem heating is required.
Flow characteristic: equal percentage; permissible leakage: max. 0.05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Installation permitted from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H679R
EAN13

7630498106422

Kvs

90 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
