Belimo H720N - 3-way globe valve DN 20

Name: Belimo H720N - 3-way globe valve DN 20
Brand: Belimo
SKU: H720N
Price: 1278.68 PLN
Availability: BackOrder

Belimo

zł1,278.68

VAT included

zł1,039.58 tax excluded

Belimo H720N is a 3-way globe valve with flanged connection, DN 20, PN 16 and Kvs 6.3 m³/h. It is designed for water-side control in ventilation and heating systems with a closed water circuit.

The medium can be water or water with a maximum of 50% vol. glycol. Medium temperature: -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H720N – 3-way globe valve

Flanged valve for water-side control in ventilation and heating systems with a closed water circuit.

Key features

DN 20, PN 16, Kvs 6.3 m³/h; stroke 15 mm.
Medium: water or water with a maximum of 50% vol. glycol; medium temperature -10...120°C [14...248°F].
Flow characteristic: A – AB equal percentage, B – AB linear.
Permissible leakage: A – AB max. 0.05% of the Kvs value; B – AB max. 1% of the Kvs value.
Pipe connection: flange; valve body: EN-GJL-250 (GG 25).

At a medium temperature of -10...2°C, the technical data sheet requires stem heating. Permitted installation position: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H720N
EAN13

7630498106736

Kvs

6.3 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
