Belimo H725N - 3-way globe valve

Name: Belimo H725N - 3-way globe valve
Brand: Belimo
SKU: H725N
Price: 1318.60 PLN
Availability: BackOrder

Belimo

zł1,318.60

VAT included

zł1,072.03 tax excluded

Belimo H725N is a 3-way globe valve with flanged connection, DN 25, PN 16 and Kvs 10 m³/h. It is designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H725N – technical data

Three-way globe valve with flanged connection for flow control in closed water systems.

Nominal diameter: DN 25; nominal pressure: PN 16; ps 1600 kPa.
Flow coefficient: Kvs 10 m³/h; stroke: 15 mm.
Fluid: water or water with a maximum of 50% by volume glycol.
Fluid temperature: -10...120°C [14...248°F]. Stem heating is recommended at fluid temperatures of -10...2°C.
Flow characteristic: A – AB: equal percentage; B – AB: linear.
Permissible leakage: A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Pipe connection: flange in accordance with ISO 7005-2.

The valve may be installed in positions ranging from vertical to horizontal relative to the stem axis. Installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H725N
EAN13

7630498106774

Kvs

10 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
