Belimo KR230 - rotary actuator for ball valves

Name: Belimo KR230 - rotary actuator for ball valves
Brand: Belimo
SKU: KR230
Price: 574.26 PLN
Availability: BackOrder

Belimo

zł574.26

VAT included

zł466.88 tax excluded

Belimo KR230 rotary actuator for ball valves, with a torque of 2 Nm. AC 100...240 V supply, Open/Close or 3-point control, and an operating time of 75 s / 90°.

Features manual adjustment using a magnet, mechanical adjustment of the rotation angle, and a position indicator. IEC/EN IP54 protection rating.

Delivery in approx. 14 days

Belimo KR230 – rotary actuator for ball valves

Electronic rotary actuator for ball valves, designed for fixed heating, ventilation and air conditioning installations. Supports Open/Close or 3-point control.

Key features and technical data

Motor torque: 2 Nm; operating time: 75 s / 90°.
Rated voltage: AC 100...240 V; frequency: 50/60 Hz.
Power consumption during operation: 1.5 W; at rest: 1 W; wire sizing power: 3 VA.
Power and control connection: 1 m cable, 3x 0.75 mm².
Manual adjustment using a magnet; Z-MA magnet included.
Mechanical position indication and rotation angle limitation adjustable in 2.5° increments; scale corresponds to 25...100% of the Kvs value.
Overload protection and automatic stop when the end stop is reached.
IEC/EN IP54 protection rating; IEC/EN protection class II, reinforced insulation.
