Belimo NRD230-3-SI - short-stroke actuator for globe valves

Name: Belimo NRD230-3-SI - short-stroke actuator for globe valves
Brand: Belimo
SKU: NRD230-3-SI
Price: 1205.40 PLN
Availability: OutOfStock

Belimo

zł1,205.40

VAT included

zł980.00 tax excluded

Short-stroke actuator for Siemens globe valves in HVAC systems. Force 500 N, AC 230 V supply, 3-point control and 5.5 mm stroke.

Motor running time is 140 s / 5.5 mm. The actuator has a 1 m cable and allows temporary or permanent disengagement of the gear train using the handwheel on the housing.

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Belimo NRD230-3-SI

Short-stroke actuator designed for Siemens short-stroke globe valves in stationary HVAC systems. It is mounted directly on the valve using a knurled nut.

Key features and technical data

Motor force: 500 N; stroke: 5.5 mm.
Rated voltage: AC 230 V; frequency: 50/60 Hz; voltage range: AC 198...264 V.
Control: 3-point; motor running time: 140 s / 5.5 mm.
Power consumption during operation: 3.5 W; power for cable sizing: 3.5 VA.
Power and control connection: 1 m cable, 3x 0.75 mm²; actuator mounting: G 3/4".
Manual adjustment: temporary or permanent disengagement of the gear train using the handwheel on the housing.
Position indicator: reversible scale plate.
Overload protection and automatic stopping when the end stop is reached.
Degree of protection IEC/EN: IP40; protection class IEC/EN: II, reinforced insulation.

Protect the actuator from moisture; it is not intended for outdoor use.

Brand

Belimo
Reference

NRD230-3-SI
EAN13

7630498105067

AC/DC voltage

AC 230 V
Power consumption (running)

3.5 W
Rated power

3.5 VA
Power supply control connection

Cable 1 m, 3x 0.75 mm²
Control type

3-point
Protection rating

IP40
Force

500 N
Manual override

Temporary and permanent gear disengagement using the knob on the housing
Stroke

5.5 mm
Running time (motor)

140 s / 5.5 mm
