Belimo NRF230A-3 - rotary actuator for ball valves
Price:
zł1,448.41
VAT included
zł1,177.57 tax excluded
Rotary actuator for ball valves with spring-return fail-safe function. Torque 10 Nm, AC 100...240 V supply and 3-point control. In the event of a power failure, the valve returns to the closed position (NC).
Motor running time is 90 s / 90°. The actuator has a mechanical position indicator and adjustable rotation angle stops.
Belimo NRF230A-3 – actuator for ball valves
Rotary actuator with spring-return fail-safe function. During operation, it moves the valve and tensions the return spring; when the power supply is interrupted, the spring moves the valve to the closed position (NC).
Key specifications and features
- Motor and fail-safe function torque: 10 Nm.
- Rated voltage: AC 100...240 V; frequency: 50/60 Hz.
- Control: 3-point.
- Motor running time: 90 s / 90°; fail-safe function operating time: <20 s @ -20...50°C, <60 s @ -30°C.
- Power consumption during operation: 4 W; at rest: 3 W; sizing power for cable selection: 15 VA.
- Power and control connection: 1 m cable, 4x 0.75 mm².
- Manual adjustment using a crank with locking switch and a mechanical position indicator.
- Rotation angle adjustment using mechanical end stops.
- Protection rating IEC/EN: IP54; NEMA/UL: NEMA 2.
Direct installation on the ball valve is achieved with one screw; the position relative to the valve can be selected in 90° increments.
-
Brand
-
ReferenceNRF230A-3
-
EAN137630498113482
-
AC/DC voltageAC 100...240 V
-
Power consumption (running)4 W
-
Power consumption (holding)3 W
-
Rated power15 VA
-
Power supply control connectionCable 1 m, 4x 0.75 mm²
-
Control type3-point
-
Protection ratingIP54
-
NEMA protection ratingNEMA 2
-
Enclosure typeUL Enclosure Type 2
