Belimo S2A-H - snap-on auxiliary switch

Name: Belimo S2A-H - snap-on auxiliary switch
Brand: Belimo
SKU: S2A-H
Price: 424.34 PLN
Availability: BackOrder

Belimo

zł424.34

VAT included

zł344.99 tax excluded

Belimo S2A-H snap-on auxiliary switch for globe valve actuators. It has two changeover contacts 2x SPDT with adjustable switching points in the range 0...100%.

It is used to indicate position or perform a switching function at a selected stroke position. It mounts directly on the actuator and is supplied with a 1 m cable, 6 x 0.75 mm².

Delivery in approx. 14 days

Belimo S2A-H auxiliary switch

The S2A-H is a snap-on auxiliary switch for globe valve actuators. It transfers the actuator position to a cam that operates a microswitch. The switching points are set using a dial, and the current switch position can be read.

Key features and technical data

Two changeover contacts: 2x SPDT; adjustable switching point 0...100%.
Position indication or switching function at a selected stroke position.
Direct mounting on a globe valve actuator.
Contact rating: 1 mA...3 A (0.5 A inductive), DC 5 V...AC 250 V / 1 mA...0.5 A (0.2 A inductive; L/R = 3.4 ms), DC 5 V...DC 110 V.
Connection: 1 m cable, 6 x 0.75 mm².
Degree of protection: IP54; NEMA 2; UL Enclosure Type 2.
Ambient temperature: 0...50°C [32...122°F].
Weight: 0.24 kg.

Adjust the auxiliary switch only when the power supply is disconnected.
