Belimo 01HT-1A - surface-mounted Pt100 temperature sensor

Name: Belimo 01HT-1A - surface-mounted Pt100 temperature sensor
Brand: Belimo
SKU: 01HT-1A
Price: 114.17 PLN
Availability: BackOrder

Belimo

zł114.17

VAT included

zł92.82 tax excluded

Passive temperature sensor for measuring the surface temperature of water pipes. Model 01HT-1A has a Pt100 output signal and a measuring range of -35...90°C [-30...195°F].

Equipped with a spring-loaded brass contact pin, spring terminals for wires up to 2.5 mm² and an enclosure with IP54 protection.

Delivery in approx. 14 days

Belimo 01HT-1A – surface-mounted temperature sensor

01HT-1A is a passive temperature sensor designed to measure the surface temperature of water pipes. The spring-loaded brass pin ensures contact with the surface being measured.

Key features

Passive temperature sensor output signal: Pt100.
Measuring range: -35...90°C [-30...195°F].
Accuracy for Pt..: Class B, ±0.3°C @ 0°C [±0.5°F @ 32°F].
Measuring current for Pt100: <1 mA @ 0°C [32°F].
Time constant τ (63%) on a water pipe, using contact fluid: typically 16 s.
Electrical connection: spring-loaded plug-in terminal block, max. 2.5 mm²; cable gland with strain relief for cable ø6...8 mm.
IEC/EN protection rating: IP54; NEMA/UL protection rating: NEMA 1.
Ambient temperature: -35...50°C [-30...120°F].
Includes A-22P-A47 fastening strap for pipes ø20...110 mm [0.8...4.3"].

For long connecting cables, allow for the effect of cable resistance on the measurement result.
