Belimo C215QP-D - 2-way PI zone valve

Belimo C215QP-D - 2-way PI zone valve

Belimo
zł494.63
VAT included
zł402.14 tax excluded

Belimo C215QP-D is a 2-way PI zone valve (PIQCV) with Rp 1/2" internal thread. DN 15, PN 25, V'nom 420 l/h; differential pressure range ∆p 16...350 kPa.

Delivery in approx. 14 days
Share

Belimo C215QP-D is a pressure-independent flow control zone valve designed for closed water systems and water-side control in ventilation and heating systems. The integrated pressure regulator maintains a constant flow rate for a given valve position within the differential pressure range of 16...350 kPa.

Key features

  • 2-way design, DN 15, PN 25; Rp 1/2" internal thread.
  • Nominal flow rate V'nom 420 l/h (0.117 l/s).
  • Differential pressure ∆p 16...350 kPa; closing pressure 1400 kPa.
  • Medium: water or water with a maximum of 50% by volume glycol.
  • Medium temperature -20...120°C [-4...248°F]; with actuator 2...90°C.
  • Equal-percentage flow characteristic; bubble-tight shut-off, class A.
  • Valve body made of brass; closing element and stem made of stainless steel.
  • Installation with the stem from vertical to horizontal; installation with the stem pointing downwards is not permitted.

  • Brand
    Belimo
  • Reference
    C215QP-D
  • EAN13
    7630498102172

  • V'nom [l/h]
    420
  • Medium
    Water, water with up to 50% vol. glycol.
  • Pattern
    2-way
  • Fluid temperature
    -20...120°C [-4...248°F]
  • Fluid temperature, note
    with actuator 2...90°C
  • Differential pressure
    ∆p 16...350 kPa
  • Closing pressure
    1400 kPa
  • Flow characteristic
    Equal-percentage characteristic
  • Permissible leakage
    Bubble-tight, leakage class A
  • Pipe connection
    Internal thread
  • V'nom [l/s]
    0.117

Techniczna karta katalogowa

Download (2.87MB)

Instrukcja montażu

Download (1.24MB)

Techniczna karta katalogowa – C2..QP(T)-..

Download (2.87MB)

EU Declaration of Conformity – C2..QP..-.. DN 15...25

Download (69.7KB)

Environmental Declaration – C..QP-..

Download (70.15KB)
