Belimo D625N - 2-way butterfly valve DN 25

Name: Belimo D625N - 2-way butterfly valve DN 25
Brand: Belimo
SKU: D625N
Price: 412.30 PLN
Availability: BackOrder

Belimo

zł412.30

VAT included

zł335.20 tax excluded

Belimo D625N is a 2-way butterfly valve DN 25 with wafer-type design, PN 6 / 10 / 16. Flow parameters: Kvs 24 m³/h and Kvmax 50 m³/h.

Designed for water and water mixed with up to 50% vol. glycol. Medium temperature: -20...120°C [-4...248°F].

Delivery in approx. 14 days

Belimo D625N – butterfly valve DN 25

2-way butterfly valve for open and closed water systems. The documentation specifies its use for switching heat sources or cooling equipment on and off.

Key features

Nominal diameter: DN 25; wafer-type design, PN 6 / 10 / 16.
Kvs 24 m³/h; Kvmax 50 m³/h.
Medium: water, water mixed with up to 50% vol. glycol.
Medium temperature: -20...120°C [-4...248°F].
Maximum differential pressure ∆pmax for DN 25: 300 kPa.
Flow characteristic: 0...60% opening angle – equal percentage; 0...100% opening angle – S-shaped.
Rotary angle: 90°; leakage rate A (EN 12266-1).
Body: EN-GJS-400-18-LT (GGG 40.3); closing element: stainless steel AISI 304 (1.4301); seat: EPDM.
Pipe connection: flange. Installation is permitted from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.
