Belimo D632NL - 2-way butterfly valve DN 32

Name: Belimo D632NL - 2-way butterfly valve DN 32
Brand: Belimo
SKU: D632NL
Price: 526.93 PLN
Availability: BackOrder

Belimo

zł526.93

VAT included

zł428.40 tax excluded

Belimo D632NL is a 2-way butterfly valve with threaded holes in the body, DN 32, PN 10 / 16. Kvs 25 m³/h, Kvmax 55 m³/h; medium temperature -20...120°C [-4...248°F].

Designed for open and closed water systems. Medium: water or water with a maximum of 50% vol. glycol.

Delivery in approx. 14 days

Belimo D632NL butterfly valve

2-way butterfly valve with threaded holes in the body, designed for open and closed water systems, including switching heat generators or cooling equipment on and off.

Key technical data

Nominal diameter: DN 32; PN 10 / 16.
Kvs: 25 m³/h; Kvmax: 55 m³/h.
Medium: water, water with a maximum of 50% vol. glycol.
Medium temperature: -20...120°C [-4...248°F].
Maximum differential pressure ∆pmax: 300 kPa.
Flow characteristic: 0...60% opening angle — equal percentage (VDI/VDE 2173); 0...100% opening angle — S-shaped.
Leakage rate A (EN 12266-1); rotation angle: 90°.
Pipe connection: flange according to ISO 7005-2 and EN 1092-2.
Body: EN-GJS-400-18-LT (GGG 40.3); closing element: AISI 304 stainless steel (1.4301); seat seal: EPDM.

Permitted installation: from vertical to horizontal position relative to the stem. Installation with the stem pointing downwards is not permitted.
