Belimo EV24A-RE - linear actuator for globe valves

Name: Belimo EV24A-RE - linear actuator for globe valves
Brand: Belimo
SKU: EV24A-RE
Price: 3658.29 PLN
Availability: BackOrder

Belimo

zł3,658.29

VAT included

zł2,974.22 tax excluded

RetroFIT+ linear actuator for 2- and 3-way globe valves. Force 2500 N, AC/DC 24 V supply, Close/Open or 3-point control, and 50 mm stroke.

Motor running time is 150 s / 40 mm (188 s / 50 mm). The actuator has push-button manual adjustment with locking option, terminal connection, and IP54 protection rating.

Delivery in approx. 14 days

Belimo EV24A-RE — RetroFIT+ actuator

Actuator for 2- and 3-way globe valves. The RetroFIT+ series is designed for installation on valves from various manufacturers using a universal valve neck adapter and stem adapter.

Key features

Actuating force: 2500 N; stroke: 50 mm.
Supply: AC/DC 24 V, 50/60 Hz; voltage range: AC 19.2...28.8 V / DC 21.6...28.8 V.
Control: Close/Open, 3-point.
Motor running time: 150 s / 40 mm (188 s / 50 mm).
Power consumption: 2.5 W while moving, 0.5 W at rest; value for cable sizing: 4.5 VA.
Power and control connection: 4 mm² terminals (cable ø4...10 mm).
Push-button manual adjustment with locking option; mechanical position indicator.
Degree of protection IEC/EN: IP54; protection class IEC/EN: III, Safety Extra-Low Voltage (SELV).
Overload protection and automatic stop when the end stop is reached.

With 3-point pulse control, ensure that the controller stops when the end position is reached. Installation may only be carried out by authorised specialists.
