Belimo H215S-G - 2-way globe valve

Belimo H215S-G – technical data

2-way globe valve for open and closed water systems and for water-side control in ventilation and heating systems.

• DN 15, PN 25; Rp 1/2" female thread in accordance with ISO 7-1.
• Kvs 1.6 m³/h; stroke 10 mm.
• Medium: water or water with up to max. 50% vol. glycol; medium temperature 0...130°C [32...266°F].
• Flow characteristic: equal-percentage (VDI/VDE 2173), optimised in the opening range.
• Permissible leakage: max. 0.01% of the Kvs value.
• Body, closing element, stem and seat: AISI 304 stainless steel; stem seal: PTFE+FFKM.
• Permitted installation: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted.

Maximum differential pressure and shut-off pressure depend on the installed globe valve actuator.
