Belimo H220S-K - 2-way globe valve DN 20

Name: Belimo H220S-K - 2-way globe valve DN 20
Brand: Belimo
SKU: H220S-K
Price: 1058.93 PLN
Availability: BackOrder

Belimo

zł1,058.93

VAT included

zł860.92 tax excluded

2-way globe valve in AISI 304 stainless steel, DN 20, PN 25, with Rp 3/4" female thread. Kvs 6.3 m³/h; medium temperature 0...130°C [32...266°F].

Delivery in approx. 14 days

Belimo H220S-K – 2-way globe valve

Valve for open and closed water systems and for water-side control in ventilation and heating systems.

Key features

DN 20, PN 25; Rp 3/4" female threaded connection according to ISO 7-1.
Kvs 6.3 m³/h; stroke 10 mm.
Medium: water or water with a maximum of 50% vol. glycol; medium temperature 0...130°C [32...266°F].
Equal-percentage characteristic (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0.01% of the Kvs value.
Body, closing element, stem and seat in AISI 304 stainless steel; stem seal PTFE+FFKM.
Permissible mounting position: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted.

During installation, observe the direction of flow indicated by the arrow on the body. The maximum differential pressure and closing pressure depend on the globe valve actuator installed.
