Belimo H240S-N - 2-way stainless steel globe valve

Belimo H240S-N – DN 40 globe valve

2-way globe valve designed for open and closed water systems and for water-side control in ventilation and heating systems.

Key features

• DN 40, PN 25; connection with Rp 1 1/2" female thread.
• Kvs 25 m³/h; stroke 20 mm.
• Fluid: water or water with up to 50% vol. glycol; fluid temperature 0...130°C [32...266°F].
• Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
• Permissible leakage: max. 0.01% of the Kvs value.
• Body, closing element, stem and seat: AISI 304 stainless steel; stem seal: PTFE+FFKM.
• Female thread in accordance with ISO 7-1; permitted mounting position from vertical to horizontal in relation to the stem.

Maximum differential pressure and closing pressure depend on the installed globe valve actuator.
