Belimo H6032X10-S2 - 2-way globe valve

Name: Belimo H6032X10-S2 - 2-way globe valve
Brand: Belimo
SKU: H6032X10-S2
Price: 2909.49 PLN
Availability: BackOrder

Belimo

zł2,909.49

VAT included

zł2,365.44 tax excluded

Belimo H6032X10-S2 is a 2-way DN 32 globe valve with a PN 25 flanged connection and Kvs 10 m³/h. Designed for water-side control in ventilation and heating systems.

Medium temperature: 5...150°C [41...302°F]. The flow characteristic is equal-percentage, and the permissible leakage is max. 0.05% of the Kvs value.

Delivery in approx. 14 days

Belimo H6032X10-S2 globe valve

2-way globe valve with a flanged connection for closed water and steam systems in non-critical applications. Designed for continuous water-side control in ventilation and heating systems.

Key features

DN 32; PN 25; Kvs 10 m³/h.
Stroke: 15 mm; n(gl): 3; Sv min.: 100.
Medium: water and steam (Δp/P1 <0,4), water with max. 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 2500 kPa, 150°C up to 2430 kPa.
Flow characteristic: equal-percentage; permissible leakage: max. 0.05% of the Kvs value.
Pipe connection: flange in accordance with ISO 7005-2.
Body: EN-GJS-400-18-LT (GGG 40.3); closing element, stem and seat: stainless steel; stem seal: PTFE V-ring.

Permissible mounting position: from vertical to horizontal in relation to the stem. Installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. Maximum differential pressure and closing pressure depend on the actuator installed.
