Belimo H6050X25-S2 - 2-way globe valve

Name: Belimo H6050X25-S2 - 2-way globe valve
Brand: Belimo
SKU: H6050X25-S2
Price: 3122.29 PLN
Availability: BackOrder

Belimo

zł3,122.29

VAT included

zł2,538.45 tax excluded

Belimo H6050X25-S2 is a 2-way globe valve with flanged connection, DN 50, PN 25 and Kvs 25 m³/h. It is designed for water-side control in ventilation and heating systems in closed water and steam circuits.

Delivery in approx. 14 days

Belimo H6050X25-S2 – 2-way globe valve

Valve for water-side control in ventilation and heating systems in closed water and steam circuits under non-critical conditions.

Key features

DN 50, PN 25, flanged connection in accordance with ISO 7005-2.
Kvs 25 m³/h; stroke 15 mm.
Media: water and steam (Δp/P1 <0,4) and water with a maximum of 50% vol. glycol.
Medium temperature: 5...150°C [41...302°F]; 120°C up to 2500 kPa, 150°C up to 2430 kPa.
Equal-percentage flow characteristic; permissible leakage: max. 0,05% of the Kvs value.
Body: EN-GJS-400-18-LT (GGG 40.3); closure element, stem and seat made of stainless steel.
Permissible installation position: from vertical to horizontal relative to the stem; installation with the stem pointing downwards is not permitted.

Maximum differential pressure and close-off pressure depend on the installed globe valve actuator.
