Belimo H610S - 2-way globe valve DN 15

Name: Belimo H610S - 2-way globe valve DN 15
Brand: Belimo
SKU: H610S
Price: 1355.95 PLN
Availability: BackOrder

Belimo

zł1,355.95

VAT included

zł1,102.40 tax excluded

Belimo H610S is a 2-way globe valve with a flanged connection, DN 15, PN 16 and Kvs 0.4 m³/h. Designed for water-side control in ventilation and heating systems.

Fluid temperature: 5...150°C [41...302°F]. Permitted fluids are water and steam (Δp/P1 <0,4), as well as water with a maximum of 50% vol. glycol.

Delivery in approx. 14 days

Belimo H610S – 2-way globe valve

Valve for closed water and steam systems in non-critical applications and for water-side control in ventilation and heating systems. The flanged connection complies with ISO 7005-2.

Key specifications

DN 15, PN 16; Kvs 0.4 m³/h.
Stroke: 15 mm.
Fluid temperature: 5...150°C [41...302°F]; 120°C up to 1600 kPa, 150°C up to 1400 kPa.
Fluid: water and steam (Δp/P1 <0,4), water with a maximum of 50% vol. glycol.
Flow characteristic: equal percentage; permissible leakage: max. 0,05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element, stem and seat: stainless steel; stem seal: PTFE V-ring.
Permitted installation: from vertical to horizontal position relative to the stem; installation with the stem pointing downwards is not permitted.

Maximum differential pressure and close-off pressure depend on the installed globe valve actuator.
