Belimo H664N - 2-way globe valve DN 65

Name: Belimo H664N - 2-way globe valve DN 65
Brand: Belimo
SKU: H664N
Price: 2765.09 PLN
Availability: BackOrder

Belimo

zł2,765.09

VAT included

zł2,248.04 tax excluded

Belimo H664N is a 2-way globe valve with flanged connection, DN 65, PN 16 and Kvs 58 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Medium: water or water with a maximum of 50% vol. glycol. Medium temperature: -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H664N – 2-way globe valve

A valve with flanged connection for closed water systems. It is used for water-side control in ventilation and heating systems.

Key features

DN 65, PN 16, ps 1600 kPa, Kvs 58 m³/h.
Stroke: 18 mm.
Medium: water, water with a maximum of 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: equal percentage (VDI/VDE 2173), optimised over the opening range.
Permissible leakage: max. 0.05% of the Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Flanged connection in accordance with ISO 7005-2.

Installation notes

Permissible installation position: from vertical to horizontal in relation to the stem. Installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. Stem heating is required when the medium temperature is -10...2°C.

Brand

Belimo
Reference

H664N
EAN13

7630498106361

Kvs

58 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
