Belimo SR24P - rotary actuator for valves

Name: Belimo SR24P - rotary actuator for valves
Brand: Belimo
SKU: SR24P
Price: 1443.36 PLN
Availability: BackOrder

Belimo

zł1,443.36

VAT included

zł1,173.46 tax excluded

Belimo SR24P rotary actuator from the RobustLine series for rotary valves. Torque 20 Nm, AC/DC 24 V supply, Close/Open or 3-point control, and running time 90 s / 90°.

IP66/67 degree of protection. The actuator has a mechanical position indicator and manual override by push-button, with the option to lock it.

Delivery in approx. 14 days

Belimo SR24P – RobustLine rotary actuator

SR24P is a rotary actuator for rotary valves, designed for use in stationary heating, ventilation and air-conditioning installations. It is mounted directly on the ball valve using a single central screw.

Key features and specifications

Torque: 20 Nm; rated voltage: AC/DC 24 V; rated voltage frequency: 50/60 Hz.
Control: Close/Open, 3-point; running time: 90 s / 90°.
Power consumption during operation: 2.5 W; at rest: 0.2 W; for cable sizing: 5.5 VA.
Power and control connection: 1 m cable, 3x 0.75 mm² (halogen-free); connecting cable FRNC.
Degree of protection IEC/EN: IP66/67; NEMA/UL: NEMA 4X; enclosure: UL Enclosure Type 4X.
Protection class IEC/EN: III, Safety Extra-Low Voltage (SELV).
Mechanical plug-in position indicator and adjustable rotation angle with mechanical stops; standard setting: 0...90°.
Manual override by push-button, with the option to lock it; requires removal of the housing cover.
Overload protection; automatic stop when the end stop is reached.
Ambient temperature: -30...50°C; ambient humidity: max. 100% RH.
