Belimo H664R - 2-way globe valve DN 65

Name: Belimo H664R - 2-way globe valve DN 65
Brand: Belimo
SKU: H664R
Price: 2252.73 PLN
Availability: BackOrder

Belimo

zł2,252.73

VAT included

zł1,831.49 tax excluded

Belimo H664R is a 2-way globe valve with PN 6 flanged connection. It has DN 65, Kvs 58 m³/h and is designed for water-side control in ventilation and heating systems.

Medium: water or water with a maximum of 50% by volume glycol. Medium temperature: -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H664R – technical data

2-way globe valve for closed water systems, designed for water-side control in ventilation and heating systems.

DN 65; PN 6 flanged connection; ps 600 kPa.
Kvs 58 m³/h; stroke 18 mm.
Medium: water or water with a maximum of 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0.05% of the Kvs value.
Body: EN-GJL-250 (GG 25); closing element and spindle: stainless steel; spindle seal: EPDM O-ring.

Installation notes

Installation is permitted from vertical to horizontal in relation to the spindle; installation with the spindle pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.

A spindle heater is required at medium temperatures of -10...2°C. The maximum differential pressure and closing pressure depend on the installed globe valve actuator.

Brand

Belimo
Reference

H664R
EAN13

7630498106378

Kvs

58 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
