Belimo H679N - 2-way globe valve DN 80

Name: Belimo H679N - 2-way globe valve DN 80
Brand: Belimo
SKU: H679N
Price: 3654.28 PLN
Availability: BackOrder

Belimo

zł3,654.28

VAT included

zł2,970.96 tax excluded

Belimo H679N is a 2-way globe valve with flanged connection, DN 80, PN 16 and Kvs 90 m³/h. Designed for water-side control in closed ventilation and heating systems.

Suitable for water and water with max. 50% vol. glycol at a fluid temperature of -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H679N – 2-way globe valve

Flanged valve for continuous water-side control in closed ventilation and heating systems. The valve plug is moved by a globe valve actuator according to the control signal.

Key features

DN 80, PN 16, Kvs 90 m³/h; stroke 18 mm.
Medium: water, water with max. 50% vol. glycol.
Fluid temperature: -10...120°C [14...248°F]. Stem heating is required at fluid temperatures of -10...2°C.
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0.05% of the Kvs value.
Pipe connection: flange according to ISO 7005-2.
Body: EN-GJL-250 (GG 25), with protective coating; plug and stem made of stainless steel, stem seal: EPDM O-ring.
Permissible mounting position: from vertical to horizontal in relation to the axis; installation with the axis pointing downwards is not permitted.

Maximum differential pressure and closing pressure depend on the actuator installed.

Brand

Belimo
Reference

H679N
EAN13

7630498106415

Kvs

90 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

Flange
