Belimo H711N - 3-way globe valve DN 15

Name: Belimo H711N - 3-way globe valve DN 15
Brand: Belimo
SKU: H711N
Price: 1196.36 PLN
Availability: BackOrder

Belimo

zł1,196.36

VAT included

zł972.65 tax excluded

Belimo H711N 3-way globe valve with flanged connection, DN 15, PN 16 and Kvs 0.63 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H711N – 3-way globe valve

Flanged valve for modulating control on the water side of ventilation and heating systems. The valve operates with a globe valve actuator.

Key features

DN 15, PN 16; Kvs 0.63 m³/h; stroke 15 mm.
Medium: water or water with a maximum of 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
Flow characteristic: A – AB equal-percentage, B – AB linear.
Permissible leakage: A – AB max. 0.05% of Kvs value; B – AB max. 1% of Kvs value.
Body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Flanged connection in accordance with ISO 7005-2.

Permitted mounting position ranges from vertical to horizontal in relation to the stem; mounting with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.

Brand

Belimo
Reference

H711N
EAN13

7630498106576

Kvs

0.63 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
