Belimo H711R - 3-way globe valve DN 15

Name: Belimo H711R - 3-way globe valve DN 15
Brand: Belimo
SKU: H711R
Price: 954.43 PLN
Availability: BackOrder

Belimo

zł954.43

VAT included

zł775.96 tax excluded

Belimo H711R is a 3-way globe valve with a PN 6 flange connection and a Kvs value of 0.63 m³/h. It is designed for closed water systems and water-side control in ventilation and heating systems.

Delivery in approx. 14 days

Belimo H711R – 3-way globe valve

Flanged valve for water-side control in ventilation and heating systems in closed water circuits.

Key features

DN 15, PN 6, Kvs 0.63 m³/h; stroke 15 mm.
Medium: water or water with a maximum of 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F]. Stem heating is required at temperatures of -10...2°C.
Flow characteristic: A – AB equal percentage, B – AB linear.
Permissible leakage: A – AB max. 0.05% of the Kvs value; B – AB max. 1% of the Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Pipe connection: flange according to ISO 7005-2.

Permissible installation position: from vertical to horizontal relative to the stem. Installation with the stem pointing downwards is not permitted. Maximum differential pressure and closing pressure depend on the actuator installed.

Brand

Belimo
Reference

H711R
EAN13

7630498106583

Kvs

0.63 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
