Belimo H712R - 3-way globe valve

Name: Belimo H712R - 3-way globe valve
Brand: Belimo
SKU: H712R
Price: 954.43 PLN
Availability: BackOrder

Belimo

zł954.43

VAT included

zł775.96 tax excluded

Belimo H712R is a DN 15 3-way globe valve with a PN 6 flanged connection and Kvs 1 m³/h. Designed for water-side control in closed ventilation and heating systems.

Suitable for water and water with a maximum of 50% by volume glycol at a medium temperature of -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H712R – 3-way globe valve

Valve for closed water systems, designed for water-side control in ventilation and heating systems. Stem heating is required at a medium temperature of -10...2°C.

Key features

DN 15, PN 6, flanged connection, Kvs 1 m³/h.
Stroke: 15 mm.
Medium: water or water with a maximum of 50% by volume glycol.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: A – AB equal percentage, B – AB linear.
Permissible leakage: A – AB max. 0,05% of the Kvs value; B – AB max. 1% of the Kvs value.
Valve body: EN-GJL-250 (GG 25); closing element and stem: stainless steel; stem seal: EPDM O-ring.
Permissible mounting position: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted.

Brand

Belimo
Reference

H712R
EAN13

7630498106620

Kvs

1 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
