Belimo H740R - 3-way globe valve DN 40

Name: Belimo H740R - 3-way globe valve DN 40
Brand: Belimo
SKU: H740R
Price: 1278.68 PLN
Availability: BackOrder

Belimo

zł1,278.68

VAT included

zł1,039.58 tax excluded

Belimo H740R is a 3-way globe valve with flanged connection, PN 6, DN 40 and Kvs 25 m³/h. Designed for closed water systems and water-side control in ventilation and heating systems.

Suitable for water or water with up to 50% vol. glycol at a medium temperature of -10...120°C [14...248°F].

Delivery in approx. 14 days

Belimo H740R – 3-way globe valve

Valve with flanged connection for closed water systems. It is used for water-side control in ventilation and heating systems.

Key features

DN 40, PN 6, Kvs 25 m³/h; stroke 15 mm.
Medium: water, water with up to 50% vol. glycol.
Medium temperature: -10...120°C [14...248°F]. At temperatures of -10...2°C, the technical data sheet requires stem heating.
Flow characteristic A – AB: equal percentage; B – AB: linear.
Permissible leakage A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value.
Body: EN-GJL-250 (GG 25); plug and stem: stainless steel; stem seal: EPDM O-ring.
Flanged connection according to ISO 7005-2.

Installation is permitted from vertical to horizontal relative to the valve axis; installation with the stem pointing downwards is not permitted. The maximum differential pressure and closing pressure depend on the actuator installed.

Brand

Belimo
Reference

H740R
EAN13

7630498106842

Kvs

25 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

3-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

A – AB: equal-percentage; B – AB: linear
Permissible leakage

A – AB: max. 0.05% of Kvs value; B – AB: max. 1% of Kvs value
Pipe connection

Flange
