Belimo R409 - 2-way control valve with orifice

Belimo R409 - 2-way control valve with orifice

Belimo
zł354.67
VAT included
zł288.35 tax excluded

Belimo R409 is a 2-way control valve with an orifice, DN 15, PN 40, with G 1" external thread. Kvs 0.63 m³/h, ps 1600 kPa; the body is made of nickel-plated brass.

Designed for water and water with up to 50% vol. glycol. Medium temperature: -10...100°C [14...212°F].

Delivery in approx. 14 days
Share

Belimo R409 – 2-way control valve

Control valve with a regulating orifice for open and closed water systems and for water-side control in ventilation and heating systems. The integrated orifice provides an equal-percentage flow characteristic. The valve is operated by a rotary actuator.

Key features

  • Pattern: 2-way; DN 15; PN 40.
  • Connection: G 1" external thread, in accordance with ISO 228-1.
  • Kvs: 0.63 m³/h; ps: 1600 kPa.
  • Differential pressure: ∆pmax 200 kPa; closing pressure: 1400 kPa.
  • Medium: water, water with up to 50% vol. glycol; medium temperature: -10...100°C [14...212°F].
  • Flow characteristic: equal-percentage; leakage rate: bubble-tight, leakage class A.
  • Body: nickel-plated brass; closing element and stem: stainless steel; regulating orifice: ETFE.

Installation notes

Permitted mounting position: from vertical to horizontal in relation to the stem; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. At a medium temperature of -10...2°C, extending the valve neck is recommended. The permitted medium temperature may depend on the actuator type.

  • Brand
    Belimo
  • Reference
    R409
  • EAN13
    7630498107979

  • Kvs
    0.63 m³/h
  • Medium
    Water, water with up to 50% vol. glycol.
  • Pattern
    2-way
  • Fluid temperature
    -10...100°C [14...212°F]
  • Fluid temperature, note
    At a fluid temperature of -10...2°C, extending the valve neck is recommended. The permissible fluid temperature may be limited depending on the actuator type. Refer to the relevant actuator data sheets for limitations.
  • Differential pressure
    ∆pmax 200 kPa
  • Closing pressure
    1400 kPa
  • Flow characteristic
    Equal-percentage characteristic
  • Permissible leakage
    Bubble-tight, leakage class A
  • Pipe connection
    External thread

Techniczna karta katalogowa

Download (776.39KB)

Instrukcja montażu

Download (556.22KB)

Techniczna karta katalogowa – R4.. modulating

Download (778.77KB)

EU Declaration of Conformity – R5.. / R4.. DN 15...50

Download (55.18KB)

Environmental Declaration – R4..

Download (70.44KB)
