Belimo 01HT-1Q - surface-mounted temperature sensor

Name: Belimo 01HT-1Q - surface-mounted temperature sensor
Brand: Belimo
SKU: 01HT-1Q
Price: 106.64 PLN
Availability: BackOrder

Belimo

zł106.64

VAT included

zł86.70 tax excluded

Passive temperature sensor for measuring the surface temperature of water pipes. Model 01HT-1Q has an NTC20k output signal and a measuring range of -35...90°C [-30...195°F].

Equipped with a spring-loaded brass contact pin, a detachable spring terminal block and an IP54-rated housing.

Delivery in approx. 14 days

Belimo 01HT-1Q – temperature sensor for pipes

Passive surface-mounted sensor for measuring the temperature on the surface of water pipes. The spring-loaded brass pin ensures contact with the measured surface.

Key technical data

Output signal: NTC20k.
Measuring range: -35...90°C [-30...195°F].
NTC20k measuring current: <0.5 mA @ 25°C [77°F].
Accuracy for NTC..: ±0.2°C @ 25°C [±0.35°F @ 77°F].
Time constant τ (63%) on a water pipe: typically 16 s when using thermal contact paste.
Electrical connection: detachable spring terminal block, max. 2.5 mm²; cable gland with strain relief for ø6...8 mm cable.
Protection rating: IP54 (IEC/EN), NEMA 1 (NEMA/UL).
Ambient temperature: -35...50°C [-30...120°F].
Included: A-22P-A47 mounting strap for pipes ø20...110 mm [0.8...4.3"].
