Belimo NRYDVX24-SR-TSI - short-stroke linear actuator

Name: Belimo NRYDVX24-SR-TSI - short-stroke linear actuator
Brand: Belimo
SKU: NRYDVX24-SR-TSI
Price: 1819.17 PLN
Availability: OutOfStock

Belimo

zł1,819.17

VAT included

zł1,479.00 tax excluded

Modulating short-stroke actuator for Siemens globe valves in HVAC systems. Thrust force 500 N, AC/DC 24 V supply and 0...10 V control.

The stroke is 5.5 mm and the running time is 35 s / 5.5 mm. The actuator provides a 0...10 V position feedback signal.

Product unavailable

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

Actuator for Siemens short-stroke valves

Belimo NRYDVX24-SR-TSI is a modulating short-stroke actuator designed to operate Siemens globe valves in stationary HVAC systems. The manufacturer's data sheet gives the type designation NRYDVX24-SR-T-SI.

Key technical data

Motor thrust force: 500 N; stroke: 5.5 mm.
Rated voltage: AC/DC 24 V; frequency: 50/60 Hz.
Control signal Y operating range: 0...10 V; position feedback signal U: 0...10 V.
Running time: 35 s / 5.5 mm.
Power consumption during operation: 1 W; power consumption for wire sizing: 2.5 VA.
Power and control connection: 4 mm² terminals (ø6...8 mm, 4-core cable).
Manual adjustment: temporary or permanent gear disengagement using the handwheel on the housing.
IEC/EN degree of protection: IP40; IEC/EN protection class: III, Safety Extra-Low Voltage (SELV).

The actuator is protected against overload and stops automatically when it reaches the end position. The manufacturer specifies that it must be protected against moisture; the device is not suitable for outdoor applications.
