Belimo C215QP-B - 2-way PI zone valve DN 15

Belimo C215QP-B - 2-way PI zone valve DN 15

Belimo
zł494.63
VAT included
zł402.14 tax excluded

Belimo C215QP-B is a 2-way PI zone valve (PIQCV) with Rp 1/2" female thread. The nominal flow rate V'nom is 210 l/h, and the differential pressure range ∆p is 16...350 kPa.

The valve is designed for closed-loop water systems and for water-side control in ventilation and heating systems.

Delivery in approx. 14 days
Share

Belimo C215QP-B – PI zone valve

2-way zone valve for pressure-independent flow control within a differential pressure range ∆p of 16...350 kPa. The integrated pressure regulator maintains a constant flow rate for a given valve position throughout this range.

Key features

  • DN 15, PN 25; Rp 1/2" female threaded connection in accordance with ISO 7-1.
  • Nominal flow rate V'nom: 210 l/h (0.058 l/s).
  • Closing pressure ∆ps: 1400 kPa.
  • Fluid: water or water with up to 50% by volume glycol.
  • Fluid temperature: -20...120°C [-4...248°F]; with actuator: 2...90°C.
  • Flow characteristic: equal percentage; leakage: bubble-tight, leakage rate A (EN 12266-1).
  • Brass body; stainless steel closing element and stem.
  • Snap-on actuator mounting.

Installation notes

Installation is permitted with the stem from vertical to horizontal; installation with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.

  • Brand
    Belimo
  • Reference
    C215QP-B
  • EAN13
    7630498102165

  • V'nom [l/h]
    210
  • Medium
    Water, water with up to 50% vol. glycol.
  • Pattern
    2-way
  • Fluid temperature
    -20...120°C [-4...248°F]
  • Fluid temperature, note
    with actuator 2...90°C
  • Differential pressure
    ∆p 16...350 kPa
  • Closing pressure
    1400 kPa
  • Flow characteristic
    Equal-percentage characteristic
  • Permissible leakage
    Bubble-tight, leakage class A
  • Pipe connection
    Internal thread
  • V'nom [l/s]
    0.058

Techniczna karta katalogowa

Download (2.87MB)

Instrukcja montażu

Download (1.24MB)

Techniczna karta katalogowa – C2..QP(T)-..

Download (2.87MB)

EU Declaration of Conformity – C2..QP..-.. DN 15...25

Download (69.7KB)

Environmental Declaration – C..QP-..

Download (70.15KB)
