Belimo D625NL - 2-way butterfly valve DN 25

Name: Belimo D625NL - 2-way butterfly valve DN 25
Brand: Belimo
SKU: D625NL
Price: 542.13 PLN
Availability: BackOrder

Belimo

zł542.13

VAT included

zł440.76 tax excluded

Belimo D625NL is a 2-way butterfly valve with threaded holes in the body, nominal diameter DN 25 and pressure class PN 10 / 16. Kvs is 24 m³/h and Kvmax is 50 m³/h.

Designed for water and water with a maximum glycol content of 50% by volume, at a medium temperature of -20...120°C [-4...248°F].

Delivery in approx. 14 days

Belimo D625NL butterfly valve

2-way butterfly valve with threaded holes in the body, designed for open and closed water systems. It can be used to switch heat generators or cooling equipment on and off.

Key technical data

Nominal diameter: DN 25; pressure class: PN 10 / 16.
Kvs: 24 m³/h; Kvmax: 50 m³/h.
Maximum differential pressure ∆pmax for DN 25: 300 kPa.
Medium: water, water with a maximum glycol content of 50% by volume.
Medium temperature: -20...120°C [-4...248°F].
Pipe connection: flange according to ISO 7005-2 and EN 1092-2.
Flow characteristic: 0...60% opening angle – equal percentage; 0...100% opening angle – S-shaped.
Angle of rotation: 90°; leakage rate A according to EN 12266-1.
Body: EN-GJS-400-18-LT (GGG 40.3); closure member: stainless steel AISI 304 (1.4301); seat: EPDM.

Permitted mounting position: from vertical to horizontal relative to the shaft. Installation with the shaft pointing downwards is not permitted.
