Belimo H225S-L - 2-way stainless steel globe valve

Name: Belimo H225S-L - 2-way stainless steel globe valve
Brand: Belimo
SKU: H225S-L
Price: 1413.59 PLN
Availability: BackOrder

Belimo

zł1,413.59

VAT included

zł1,149.26 tax excluded

Belimo H225S-L is a 2-way stainless steel globe valve, DN 25, PN 25, with Rp 1" female thread. Kvs is 10 m³/h, and the medium temperature is 0...130°C [32...266°F].

Designed for water-side control in ventilation and heating systems, in open and closed water circuits.

Delivery in approx. 14 days

Belimo H225S-L – 2-way globe valve

Female-threaded valve for water-side control in ventilation and heating systems. It can operate in open and closed water circuits. The body, closing element, stem and seat are made of AISI 304 stainless steel.

Key technical data

Type: H225S-L; version: 2-way.
DN 25, PN 25; connection: Rp 1" female thread in accordance with ISO 7-1.
Kvs: 10 m³/h; stroke: 15 mm.
Medium: water, water with max. 50% vol. glycol.
Medium temperature: 0...130°C [32...266°F].
Flow characteristic: equal percentage (VDI/VDE 2173), optimised in the opening range.
Permissible leakage: max. 0.01% of the Kvs value.
Stem seal: PTFE+FFKM.

Permissible mounting position: from vertical to horizontal in relation to the stem; mounting with the stem pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body.
