Belimo H412B - 2-way globe valve DN 15

Name: Belimo H412B - 2-way globe valve DN 15
Brand: Belimo
SKU: H412B
Price: 629.53 PLN
Availability: BackOrder

Belimo

zł629.53

VAT included

zł511.81 tax excluded

Belimo H412B is a 2-way globe valve with G 1 1/8" male thread, DN 15, PN 16 and Kvs 1 m³/h. It is designed to control the flow of water or water mixed with up to 50% vol. glycol.

Delivery in approx. 14 days

Belimo H412B – 2-way globe valve

Valve for open and closed water systems and for water-side control in ventilation and heating systems.

Key features

DN 15, PN 16, ps 1600 kPa.
G 1 1/8" male thread, pipe connection in accordance with ISO 228-1.
Kvs 1 m³/h; stroke 15 mm.
Medium temperature: -10...120°C [14...248°F].
Flow characteristic: equal-percentage; permissible leakage: max. 0.05% of the Kvs value.
Valve body: CC499K; closing element and stem: stainless steel; stem seal: EPDM O-ring.

Installation notes

Permitted installation position: from vertical to horizontal relative to the valve axis; installation with the axis pointing downwards is not permitted. Observe the flow direction indicated by the arrow on the body. Stem heating is required at a medium temperature of -10...2°C.

Brand

Belimo
Reference

H412B
EAN13

7630498105586

Kvs

1 m³/h
Medium

Water, water with up to 50% vol. glycol.
Pattern

2-way
Fluid temperature

-10...120°C [14...248°F]
Fluid temperature, note

When the medium temperature is -10...2°C, shaft heating is recommended.
Flow characteristic

Equal-percentage characteristic
Permissible leakage

Max. 0.05% of Kvs value
Pipe connection

External thread
